CX-513YQ NEW

CX-513YQ is designed to pick up Dulcimer. This three microphone kit covers from low to high end frequency and reproduces each thrill and harmonic. The low profile design renders photographic and filming easy on stage.

WHAT YOU GETIS SUITABLE FOR

INSTRUMENT

SPECIFICATIONS

CX-513YQ
Type	Omni-directional Condenser
Frequency Response	20~20,000 Hz
Sensitivity (at 1,000Hz)	-58±3dB(1.25mV)0dB=1V/μbar
Impedance	1.5kΩ
Max.SPL for 1% T.H.D.	130 dB
Signal-To-Noise Ratio	68 dB
Output Connector	4P Mini XLR
Power Supply	1-5 VDC
Current Consumption	≤0.5mA
Weight	6.5 grams (including cable)
Dimensions(mm)	Ø6mm(W)*13mm(H)
Standard Accessory	MA-500
